10.3.3 LIST

Displays a variety of information on the OAM protocol status in the Ethernet interface that is being monitored. The
following options are available:
10.3.3.1 LIST DISCOVERY
Displays configuration information on the local OAM client and, where available, on the remote OAM client.
Syntax:
ethernet0/1 OAM monitor+list discovery
Example:
ethernet0/1 OAM monitor+list discovery
Local client configuration
Mode: active
Unidirection: not supported
Link Monitor: supported
Remote loopback: supported
MIB retrieval: not supported
MTU size: 1500
Remote client configuration
MAC address: 0012430816D1
Mode: active
Unidirection: not supported
Link Monitor: supported
Remote loopback: supported
MIB retrieval: not supported
MTU size: 1500
Organizationally Unique Identifier (OUI): 0x0C0
ethernet0/1 OAM monitor+
10.3.3.2 LIST RUNTIME
Displays internal information on the OAM protocol, such as the status variables for the different OAM subsystems
(Discovery, Parser and Multiplexer), status of the OAM timers, the current status for the Discovery states machine,
etc.
Syntax:
ethernet0/1 OAM monitor+list runtime
Example:
ethernet0/1 OAM monitor+list runtime
Runtime settings
Local_pdu: ANY
Local_mux: FWD
Local_par: FWD
Local_link_status: OK
Local_satisfied: YES
Local_stable: YES
Loopback_state: OFF
PDU_cnt: 9
PDU_timer: ON
Lost_link_timer: ON
Link_monitor_timer: ON
Loopback_timer: OFF
Remote_state_valid: YES
Remote_stable: YES
Remote_evaluating: NO
Current local Discovery FSM state: SEND_ANY
ethernet0/1 OAM monitor+
