8 Switch Monitoring
InMulticasts:
InFCSErr:
AlignErr:
InGoodOctets:
InBadOctets:
Undersize:
Fragments:
In64Octets:
In127Octets:
In255Octets:
In511Octets :
In1023Octets :
InMaxOctets:
Jabber:
Oversize:
InDiscards:
Filtered:
OutUnicasts:
OutBroadcasts:
OutPause:
OutMulticasts:
OutFCSErr:
OutGoodOctets:
Out64Octets:
Out127Octets:
Out255Octets:
Out511Octets :
Out1023Octets :
OutMaxOctets:
Collisions:
Late:
Excessive:
Multiple:
Single:
Deferred:
OutFiltered:
Note
Some devices do not support an atomic reading of all counters. If any counters are updated during the
reading, an asterisk is shown next to the value of the counter to warn about possible inaccuracies.
8.3.4.14 LIST STATS CPU-PORT
Displays the statistics for the switch port connected to the CPU.
Syntax:
ethernetX/X Switch+list stats cpu-port
Example 1:
ethernet0/2 Switch+list stats cpu-port
78
Multicast packets received.
Packets received with CRC error.
Packets received with alignment errors.
Bytes received without errors.
Bytes received with errors.
Undersized packets received with correct CRC.
Fragments received with CRC, alignment or symbol errors.
Total packets received with a length equal to 64 octets.
Total packets received with lengths between 65 and 127 octets.
Total packets received with lengths between 128 and 255 octets.
Total packets received with lengths between 256 and 511 octets.
Total packets received with lengths between 512 and 1023 octets.
Total packets received with lengths between 1024 octets and the maximum per-
mitted frame.
Oversized packets with CRC, alignment or symbol errors.
Oversized packets received with correct CRC.
Packets discarded due to lack of resources at the switch.
If VLAN is not enabled in the port, this indicates the number of packets received
that were not forwarded to another port. If VLAN is enabled in the port, this indic-
ates the number of packets that have been dropped due to an unknown VLAN
identifier.
Unicast packets transmitted.
Broadcast packets transmitted.
Pause packets transmitted.
Multicast packets transmitted.
Packets transmitted with CRC error.
Bytes transmitted.
Packets transmitted with a 64 byte length.
Packets transmitted with a length between 65 and 127 bytes.
Packets transmitted with a length between 128 and 255 bytes.
Packets transmitted with a length between 256 and 511 bytes.
Packets transmitted with a length between 512 and 1023 bytes.
Packets transmitted with a length between 1024 and 1522 bytes.
Total number of detected collisions. Only logical in half duplex mode.
Number of late detected collisions.
Packets not transmitted due to excessive collisions.
Packets transmitted after multiple collisions.
Packets transmitted after a single collision.
Packets transmitted after delaying transmission due to busy medium when trans-
mitting.
Packets filtered at the output.
