8 Switch Monitoring
Example:
ethernet0/0 Switch+list mac-address 00A0267C0043
DBNum Entry
-----------------------------------------------------------
0 1
ethernet0/0 Switch+
8.3.4.8 LIST REGISTERS
Displays the content of the switch's internal registers.
Syntax:
ethernetX/X Switch+ list registers ?
global
physical
port
global
physical
port
Example:
ethernet0/0 Switch+list registers global
Print Global (Set-1) registers device 1
0 ... e804
8 ... 0000
10 ... 0000
18 ... fa50
Print Global (Set-2) registers device 1
0 ... 0000
8 ... 0000
10 ... 0000
18 ... 18e1
Print Global (Set-1) registers device 2
0 ... e854
8 ... 0000
10 ... 0000
18 ... fa50
Print Global (Set-2) registers device 2
0 ... 0000
8 ... 0000
10 ... 0000
18 ... 1801
ethernet0/0 Switch+list registers physical 1
Print PHY registers port 1 (hwport 7)
0 ... 3100
8 ... 0000
10 ... 4130
18 ... 42bf
ethernet0/0 Switch+list registers port 1
Print PORT registers port 1 (hwport 7, devnum 1)
0 ... fd06
8 ... 0080
10 ... 0000
18 ... 3210
ethernet0/0 Switch+
8.3.4.9 LIST REMOTE-STATUS
Displays information on the status of the remote end connected to each switch port.
Syntax:
ethernetX/X Switch+list remote-status
Example 1:
72
Dev Prio PortMap Port
1 0 0x0001 1
Global switch registers
Physical switch registers
Port switch registers
Switch global registers.
Registers associated to the PHYTER for a switch port.
Registers associated to a switch port.
0000 0000 0000 440a 1000
0000 0161 4000 0807 00a0
0000 5555 5555 aaaa aaaa
0000 ffaf 00f4 2001 4c12
0000 ffff 0008 0258 04ff
3707 0000 1000 07ff 0000
0000 0000 0000 0000 0000
78ed 0000 f869 0000 07ff
0000 0000 0000 440a 1000
0000 0161 4000 1007 00a0
0000 5555 5555 aaaa aaaa
0000 ff8f 00f8 2002 4c12
0000 ffff 0008 0258 04ff
3f01 0004 1000 07ff 0000
0000 0000 0000 0000 0000
78c9 0000 f869 0000 07ff
78ed 0141 0c89 05e1 45e1
0000 0000 0000 0000 0000
7c00 6c01 0000 0000 0000
0000 0000 0000 0002 0000
0003 9f00 0992 007f 0000
0001 8000 0080 0000 0000
0000 0000 0000 0000 0000
7654 610c 0024 0000 0c84
State MAC Address
0x1 00A0267C0043
0000 0000
267c 0043
ffff ffff
0003 fc0d
0208 07ff
000c 0000
0000 0000
0000 0000
0000 0000
267c 0043
ffff ffff
0000 0000
0000 07ff
000c 0000
0000 0000
0000 0000
0007 2801
0000 0000
4a34 03fc
0000 0000
077f 0001
0000 9100
0000 000f
0022 4444
