0 16
0 17
0 18
ethernet0/0 Switch+
The meaning of the fields is as follows:
DBNum:
Entry:
Dev:
Prio:
PortMap:
Port:
State:
This value depends on the type of MAC address installed in the table. This can take the following values:
State
0x0
0x1
0x8, 0x9, 0xA, 0xB, 0xC,0xD, 0xE, 0xF
0x4, 0x5, 0x6, 0x7, 0xC, 0xD, 0xE, 0xF
MAC ADD
8.3.4.6 LIST MAC-TABLE
Displays all the MAC addresses learned by the switch.
Syntax:
ethernetX/X Switch+list mac-table
Example 1:
ethernet0/0 Switch+list mac-table
Entry Type
--------------------------------------------------------
1 D
2 D
3 D
4 D
5 D
The meaning of the fields is as follows:
Entry:
Type :
FID:
PortId:
MAC ADD:
Age Timer:
8.3.4.7 LIST MAC-ADDRESS
Displays the contents of the MAC addresses table associated to a specific MAC address.
Syntax:
ethernetX/X Switch+list mac-address <mac>
LAN Interfaces
1 0 0x0001 1 0x1
1 0 0x0001 1 0x1
1 0 0x0001 1 0x1
Internal database identifier where the MAC address is located. For VLANs, each
VLAN handles a different internal database.
Entry identifier in the MAC table.
In switches made up of various modules, module identifier.
Priority associated to the MAC entry.
Port map for those sending frames with the specified MAC. For dynamic ad-
dresses, this corresponds to the port the MAC has been learned through.
Switch port through which the MAC address has been learned. With static ad-
dresses, this field is not active whenever a packet can be transmitted through vari-
ous ports.
State of the MAC entry.
Learned MAC address.
FID PortId MAC Address
0 1 00-0c-29-60-1b-ee
0 1 40-61-86-f7-18-07
0 1 00-16-e6-38-eb-da
0 1 3c-d9-2b-56-16-24
0 1 f0-1f-af-ec-a6-f1
Entry identifier in the MAC table.
Indicates if the entry is static or dynamic address.
Identifier used to discriminate between the 16 VLANs that can be defined in the
switch.
Switch port the MAC address has been learned through.
Learned MAC address.
Aging time for MAC address table entries. Ranges from 1 to 3600 seconds.
020001110005
020001110007
90E6BADF9B88
MAC Type
Invalid entry.
Unicast dynamic.
Static Unicast.
Static Multicast.
Age Timer
220
300
220
180
300
8 Switch Monitoring
