KIT CONTENTS: We have organized the parts as they come out of the box for better identification
during assembly. We recommend that you regroup the parts in the same manner. This will ensure you
have all of parts required before you begin assembly.
AIR FRAME ASSEMBLIES
(2) Wing halves with ailerons
(1) Fuselage with canopy.
(1) Horizontal stabilizer with elevator halves
(1) Vertical stabilizer with rudder
(1) Cowling
(1) Decal sheet
(1) Instruction manual
MAIN GEAR ASSEMBLY
(2) Main gear
(2) 60mm diameter wheels
(2) connector gear
(2) Metal rod 1.7mm x 30mm
(2) Metal clevises M2
(2) Metal connector
(2) Plastic cover
(8) 2mm x 10mm screws
TAIL GEAR ASSEMBLY
(1) Tail gear
(1) 25mm diameter wheel
(2) Wheel collar
(2) plastic clasp
(6) 2mm x 10mm screws

KIT CONTENTS

ELEVATOR CONTROL SYSTEM
(2) Metal clevis M2
(1) Nylon clasp
(2) Nylon control horn
(4) 2mm x 20mm screw
(1) Domino
(1) Metal rod.
RUDDER CONTROL system
(1) Metal clevis M2
(1) Nylon clasp
(1) Nylon control horn
(2) 2mm x 20mm screw
AILERON CONTROL SYSTEM
(2) Metal rod 1,7mm x 30mm
(2) Metal clevis M2
(2) Nylon clasp
(2) Nylon control horn
(4) 2mm x 20mm screw
(4) Hard wood block
(8) 2mm x 12mm screw
ENGINE MOUNT
(4) 3mm x 20mm screw
(4) 3mm lock washer
1
THROTTLE CONTROL SYSTEM
(1) Metal rod 1,2mm x 500mm
(1) Nylon housing 3,5mm x 350mm
(1) Metal connector
(1) 4mm x 4mm screw
FUEL TANK
(1) Fuel tank
(1) Metal clunk
(1) 110mm silicon tube
(1) Stopper
(1) 80mm x 120mm foam.
MISCELLANEOUS ITEMS
(1) Dihedral
(1) Spinner
(1) 25mm x 600mm trim tape
(4) Plastic screw
(2) Plastic plate
(4) 2,6mm x 10mm screw
(1) Decal sheet
(3) Metal rod 1,7mm x 900mm
(2) Plastic belly pan fairings
