30
Fix the wing and apply the trim tape to the center section
on the top of the wing where they join.
Installing the landing gear servo.
4
32
Install the gear servo.
34
Install the servo arm and attach two rods to the metal
connector, secure the servo arm.
Installing the horizontal stabilizer and vertical stabilizer.
5
35
Make a center line onto the horizontal.
Center line
31
Apply the trim tape to the center section on the bottom of
the wing where they join.
33
Install two metal connector to the servo arm.
36
Remove the covering from the rear of the fuselage.
6
