Installing the aileron servo and linkage.
Installing the aileron servo and linkage.
1
1
Remove the covering from the top of the wing.
3
Four blocks of hard wood.
5
Install the aileron servo.
7
Tape the servo lead into the end of the thread.
2
Remove the covering from the aileron servo box.
4
Glue the two hard wood by C.A glue.
6
Connect the aileron servo to the 230mm servo extension
(not included in the kit).
8
Tape
Pull the servo lead out.
2
230mm
Tape
