9
Using the masking tape, tape the servo lead onto the top of
the wing.
11
The control horn of the aileron.
13
Secure the control horn.
Wing
Control horn
Aileron
Wrong
10
Secure the aileron servo box.
12
Mark two holes from the control horn onto the bottom of
the aileron and INLINE with the servo arm.
Wing
14
Silicone tube
Metal clevis
Install the metal clevis to the aileron pushrod.
3
Control horn
Aileron
Correct
Nut
