Installing the fuel tank.

9
74
Secure the stopper.
76
Slide the fuel tank to the fuselage.

Installing the engine.

10
78
Drill a holes for throttle rod.
73
Install the stopper to the tank.
75
Install the silicone tube of the tank.
77
Secure the fuel tank in place by rubber bank.
79
Insert the plastic tube to the fuselage and secure it by
C.A glue.
12
