KIT CONTENTS: We have organized the parts as they come out of the box for better identification
during assembly. We recommend that you regroup the parts in the same manner. This will ensure you
have all of parts required before you begin assembly.
MAIN GEAR ASSEMBLY
• (2) Main gear Aluminum
• (2) 65mm diameter wheels
• (2) Set of axles
• (2) Fiberglass wheel pants
• (4) 4mm x 20mm machine screws
• (4) 8mm flat washers
• (4) Lock washers
TAIL WHEEL ASSEMBLY
• (1) Tail wheel bracket w/wire
• (1) 25mm diameter wheel
• (2) 2mm wheel collar
• (2) Nylon control clasp
• (2) 2mm x 16mm wood screw
ELEVATOR CONTROL SYSTEM
• (2) Set aluminum control horn
• (4) 2mm x 30mm screw
• (2) M2 metal clevis
• (2) Silicone tube
• (1) Nylon snap keeper
• (1) Metal domino
• (1) 1.7mm x 100mm metal rod
RUDDER CONTROL SYSTEM
• (1) Set aluminum control horn
• (2) 2mm x 30mm screw
• (1) M2 metal clevis
• (1) Silicone tube
• (1) Nylon snap keeper
AILERON CONTROL SYSTEM
• (2) Set aluminum control horn
• (4) 2mm x 30mm screw
• (2) M2 metal clevis
• (2) Silicone tube
• (2) Nylon snap keeper
• (2) 1.7mm x 180mm metal rod

KIT CONTENTS

1
MOTOR MOUNT ASSEMBLY
• (1) Nylon engine mount
• (4) 4mm x 25mm metal screw
• (8) Flat metal washer
• (4) Lock metal washer
• (4) 3mm x 20mm screw
THROTTLE CONTROL SYSTEM
• (1) 1,3mm x 500mm metal pushrod
• (1) 3,5mm x 350mm nylon pushrod housing
• (1) Metal connector
FUEL TANK
• (1) Nylon fuel tank
• (1) Pre - assembled stopper w / 3 tube
• (1) Metal clunk
MISCELLANEOUS ITEMS
• (1) 19mm x 348mm diameter aluminum dihedral
• (4) 6mm x 45mm nylon screws
• (2) 4mm x 30mm wood screws
• (4) 2.6mm x 10mm wood screws
• (1) Spinner
• (1) Block of wood
• (3) 1.7mm x 800mm metal rod
• (1) Cowling
• (1) Decal sheet
