Installing The Throttle Servo - Phoenix Model SPITFIRE Instruction Manual

Arf
Hide thumbs Also See for SPITFIRE:
Table of Contents

Advertisement

80
Attach the engine to the engine mount and mark four holes
(this picture use the 52 OS engine four stroke).
82
Attach the throttle rod to the arm of the carburator.
84
Install the silicone exhaust (not included in the kit).

Installing the throttle servo.

11
85
Install the throttle servo.
108 mm
81
Drill four holes onto the engine mount.
83
Install the engine and secure it.
86
Install the metal connector to the servo arm.
