LPOD-R Outdoor Amplifier / Block Up Converter (BUC)
System Connectors, Installation, and Startup
CEFD KIT / QTY REQ'D
ITEM
KT- KT-
0000083 0000084
1 –
– 1
1
– –
– –
2 2 2
3 2 2
4 2 2

Figure 2-11. LPOD-R PS 1, PS 1.5 Spar Mount Installation Kits

CEFD PART NO.
KT- KT-
0000085 0000289
– – FP-0000547
– – FP-0000546
1 – FP-0000545
– 1 FP-0001330
2 2 HW/1/4-FLT
2 2 HW/1/4-SPLIT
HW/1/4-20X1-
2 2
1/4HEX
2–21
MN-LPODR
Revision 3
DESCRIPTION
[dims in mm]
BRACKET, MOUNTING,
1.5" x 2.0" [38.1 X 50.8] SPAR
BRACKET, MOUNTING,
1.75" x 4.0" [44.4 X 101.6] SPAR
BRACKET, MOUNTING,
1.0" x 2.5" [25.4 X 63.5] SPAR
BRACKET, MOUNTING,
72mm x 72mm SPAR
FLAT WASHER, 1/4
LOCK WASHER, SPLIT, 1/4
BOLT, HEX HEAD
1/4-20 x 1-1/4" LG
