LPOD-R Outdoor Amplifier / Block Up Converter (BUC)
System Connectors, Installation, and Startup
CEFD KIT / QTY REQ'D
ITEM
KT-0020707 KT-0020708
LENGTH A/R
1
– LENGTH A/R
1
2
–
2.1 1
2.2 1
2.3 1
1
2.4
–
2.5 1
2.6 1

Figure 2-4. LPOD-R Ethernet Connector Field Termination Kit Assembly

Assembly Detail Source: Samtec USA Corporation)
SAMTEC PART NO.
– N/A – BY USER (not part of kit)
N/A – BY USER (not part of kit)
– RCEF-G-01
1 RCEF-G-02
1 SUB-MODP-01-8P8C-S-01
1 RCEF-B-02
1 RCEF-B-01
– SG-17-01
1 SG-17-02
1 NCC-17-01
1 SCN-17-02
2–10
MN-LPODR
Revision 3
DESCRIPTION
5.6mm OD 8-wire CAT5e
Ethernet Cable
6.5mm OD 8-wire CAT5e
Ethernet Cable
Samtec Weatherproof Connector
Assembly (Items 2.1-2.6)
RJ-45 Modular Ethernet Plug
Ethernet Shroud, Nylon
Latched Housing, Nylon
Sealing Gland, Neoprene
(for 5.0-5.75mm OD Cable)
Sealing Gland, Neoprene
(for 5.75-6.5mm OD Cable)
Compression Cage, Nylon
Cable Nut, Nylon
