A.1 Overview
This appendix provides line details for the cables available for use with the LPOD-R in standalone applications. Each figure illustrates
the cable's technical specifications – e.g., connector types used, cable labeling, wiring lists, etc.
A.2 Control and Data Cables
Figure CEFD CABLE P/N DESCRIPTION
Serial Interface Cable
A-1 CA-0020526
(19-pin circular connector to RJ-11)
Ethernet Interface Cable
A-2 CA-0000352
(19-pin circular connector to <2X> RJ-45)
CAT5e Ethernet Cable
A-3 PP/CAT5FF7FTGY
(RJ-45 to RJ-45)

Appendix A. CABLE DRAWINGS

USED FOR:
Connecting a standalone LPOD-R PS 1 or PS 1.5 original version (now optional) 19-pin 'J6 |
COM1' receptacle to the CLC-10 RJ-11 comms jack
(Cable and CLC-10 are furnished as part of optional CEFD KIT KT-0020518)
Connecting a standalone LPOD-R PS 1 or PS 1.5 original version (now optional) 19-pin 'J6 |
COM1' receptacle to an LPODnet or a user PC Ethernet jack
(Cable and LPODnet are furnished as part of optional CEFD KIT KT-0000203)
Connecting a standalone LPOD-R PS .5, PS 1, or PS 1.5 current production version RJ-45 'J6
| COM1' weatherproof receptacle to an LPODnet or a user PC Ethernet jack.
(LPODnet is furnished as part of optional CEFD KIT KT-0000203)
RECOMMENDED ONLY FOR TEMPORARY APPLICATIONS.
A-1
