Receiver Keys

AVTM246004 BITE 2/2P Rev 4 July 2011
Find Quality Products Online at:
CONTROLS, CONNECTORS, INDICATORS AND MENUS
7-pin connector—The 7-pin connector is used to insert one
of the following: RS-232 communication cable, bar-code wand
(optional), potential probe or printer.
4-pin connector—The 4-pin connector is used to connect the
current sensor (CT).
3-pin connector—The 3-pin connector is used to connect the
battery charger.
Buzzer—The buzzer prompts the user to input data. It also
sounds under certain error conditions.
There are three keys located on the receiver that are used to
operate the receiver and to navigate through the menus and
displays on the LCD screen:
The UP ARROW and DOWN ARROW keys are
used to select information displayed next to
these keys on the screen. These keys are also
used to scroll up and down through receiver
screens.
The ENTER key is used to access receiver
menus, which are shown in Figure 3-6
through Figure 3-7.
19
