Connection to Power Source

Fuse Replacement

See "Maintaining Fuses in the BITE 2
and BITE 2P Transmitters" on page
78 for detailed instructions on fuse
replacement.

Cautions and Warnings

AVTM246004 BITE 2/2P Rev 4 July 2011
Find Quality Products Online at:
The BITE 2/2P test instruments operate from a single-
phase power source. The three-wire power cord requires a
two-pole, three-terminal, live, neutral, and ground type
connector. The voltage to ground from either pole of the
power source must be 100 – 240 volts (50-60 Hz)
nominal. Do NOT exceed 264 V max.
Before connecting to the ac power source, determine that
the instrument rating matches the voltage of the power
source and has a suitable two-pole, three-terminal
grounding type connector.
The power input plug must be inserted only into a mating
receptacle with a ground contact. Do not bypass the
grounding connection. Any interruption of the grounding
connection can create an electric shock hazard. Make
sure that the receptacle is properly wired before inserting
the plug.
Depending on whether the test set is supplied with a
black, white and green input supply cord or a brown,
blue and green/yellow supply cord, the black or brown
cord lead must be connected to the live pole and the
white or blue cord lead must be connected to the neutral
pole of an approved power input plug. The green or
green/yellow ground lead of the input supply cord must
be connected to the protective ground (earth) contact of
the input plug.
Refer fuse replacement to qualified personnel only. To
avoid electric shock and fire hazard, use only the fuse
specified (see Appendix B), which is identical with respect
to type, voltage rating, and current rating.
This manual provides cautions and warnings where
applicable, and these safety features should be strictly
observed.
11
