Product description

The display

The LCD display is located on the front casing of the blood pressure monitor (see Fig. 1). It displays useful
information for the doctor and the patient regarding measurement data, blood pressure monitor settings and
measurement errors.

Audible signals

The audible signals used consist of individual or multiple burst sequences.
The following burst sequences are emitted:
Tone burst
1 tone burst
3 tone bursts
Continuous tone bursts
Combined tone bursts

Cuff connection

The cuff connection is located on the front casing of the Mobil-O-Graph
to connect the blood pressure monitor to the cuff via the cuff tube and the metal sleeve of the cuff.
84
Heard when
▪
Switching on and off
▪
Starting and ending measurement (except during the night-time
interval)
▪
Removing the interface cable, ending IR communications,
establishing and ending Bluetooth communications
▪
Measurement errors
▪
System error (e.g. measurement terminated)
▪
Serious system error (e.g. the cuff pressure is greater than 15 mmHg
for more than 10 seconds outside the measurement)
▪
When manually clearing the readings, 1 tone burst is emitted first
and 2 seconds later 5 tone bursts
®
(see Fig. 1). This metal plug is needed
