ATTENTION
The metal plug (air coupling) must always engage with an audible "click". Otherwise there will be a leaky
connection between the Mobil-O-Graph

Data socket

The data socket is located on the left side of the casing (see Fig. 1). The connection cable provided is connected
to this socket. This is a plug connection; the red dot of the plug must be plugged onto the red dot of the socket.
Pull the outer metal ring to release the connection.
Further information can be found in the HMS CS operating manual.

Infrared interface

The infrared interface provides an equivalent wireless alternative to the data socket. To use this interface, you
need the PC infrared interface IR-Med. The infrared interface can be obtained from your specialist supplier.
Further information can be found in the HMS CS operating manual.

3.4 Preparation for measurement

▪
Connect the tube extension to one of the cuffs provided by putting it on the plastic connector.
▪
Connect the tube of the cuff to the plug on the front casing of the blood pressure monitor.
▪
First of all, check that the power packs are inserted correctly. You should always use fully charged power
packs for a new measurement. Alternatively, you can also use alkaline batteries. When inserting the
power pack or batteries, please ensure correct polarity.
®
and tube which will lead to measurement errors.
