Silicon Laboratories SI5351A/B/C Product Manual page 51

Register 73. Multisynth3 Parameters
Bit D7
Name
Type
Reset value = xxxx xxxx
Bit Name
7:0 MS3_P2[7:0]
Register 74. Multisynth4 Parameters
Bit D7
Name
Type
Reset value = xxxx xxxx
Bit Name
7:0 MS4_P3[15:8]
Register 75. Multisynth4 Parameters
Bit D7
Name
Type
Reset value = xxxx xxxx
Bit Name
7:0 MS4_P3[7:0]
D6 D5 D4
Multisynth3 Parameter 2.
This 20-bit number is an encoded representation of the numerator for the fractional
part of the Multisynth3 divider.
D6 D5 D4
Multisynth4 Parameter 3.
This 20-bit number is an encoded representation of the denominator for the frac-
tional part of the Multisynth4 divider.
D6 D5 D4
Multisynth4 Parameter 3.
This 20-bit number is an encoded representation of the numerator for the fractional
part of the Multisynth4 divider.
Preliminary Rev. 0.95
D3 D2
MS3_P2[7:0]
R/W
Function
D3 D2
MS4_P3[15:8]
R/W
Function
D3 D2
MS4_P3[7:0]
R/W
Function
Si5351A/B/C
D1 D0
D1 D0
D1 D0
51
