Silicon Laboratories SI5351A/B/C Product Manual page 41

Register 46. Multisynth0 Parameters
Bit D7
Name
Type
Reset value = xxxx xxxx
Bit Name
7:0 MS0_P1[7:0]
Register 47. Multisynth0 Parameters
Bit D7
Name
Type
Reset value = xxxx xxxx
Bit Name
7:4 MS0_P3[19:16]
3:0 MS0_P2[19:16]
Register 48. Multisynth0 Parameters
Bit D7
Name
Type
Reset value = xxxx xxxx
Bit Name
7:0 MS0_P2[15:8]
D6 D5 D4
Multisynth0 Parameter 1.
This 18-bit number is an encoded representation of the integer part of the
MultiSynth1 divider.
D6 D5 D4
MS0_P3[19:16]
R/W
Multisynth0 Parameter 3.
This 20-bit number is an encoded representation of the denominator for the frac-
tional part of the MultiSynth0 Divider
Multisynth0 Parameter 2.
This 20-bit number is an encoded representation of the numerator for the fractional
part of the MultiSynth1 Divider.
D6 D5 D4
Multisynth0 Parameter 2.
This 20-bit number is an encoded representation of the numerator for the fractional
part of the MultiSynth1 Divider.
Preliminary Rev. 0.95
D3 D2
MS0_P1[7:0]
R/W
Function
D3 D2
MS0_P2[19:16]
Function
D3 D2
MS0_P2[15:8]
R/W
Function
Si5351A/B/C
D1 D0
D1 D0
R/W
D1 D0
41
