1. HANDLING THE PACKAGED MACHINE

The machine is contained within specific packaging.
It is not possible to place more than two packages on top of each other.
The total weight is 130kg (without batteries) for Mx models
Total weight is 175kg for SMx models
The overall dimensions of the package are:
Mx VERSIONS
A : 1260mm
B : 720mm
C : 1660mm
SMx VERSIONS
A : 1760mm
B : 1020mm
C : 1270mm

2. HOW TO UNPACK THE MACHINE

1. Remove the outer packaging
2. The machine is fixed to the pallet with wedges which block the wheels
3. Remove these wedges
4. Use a chute to get the machine down from the pallet, pushing it backwards. Avoid violent blows to the
brush head
5. Keep the pallet for any future transport needs
