32. REVERSE FUNCTION

To activate the reverse direction, just push the command levers (1) downwards.
WARNING: When moving backwards even for brief moments,
check that squeegee is raised, and check the brush head is also
raised when the machine is not working.
33.

PRIMING OF DETERGENT PUMP (VERSIONS WITH FSS)

The detergent pump must be primed before starting work; proceed as follows to do so:
1. Check that the main switch of the machine is set to "Off – 0"
2. Verify that the battery connector is disconnected from the machine connector
3. Check that the parking brake is correctly engaged.
4. Make sure the recovery tank is empty, otherwise empty it completely
5. Disconnect the tank closure hinge (1) By gripping the handle (2) on the left side of the machine, turn
the recovery tank
6. Unscrew the cap of the detergent canister (3) and fill it with the desired product
WARNING: always use low foam detergent. To avoid the production of foam,
before starting to clean, put a minimum quantity of antifoam liquid into the
recovery tank. Do not use pure acids.
7. Close the cap of the detergent canister, taking care that the suction filter is positioned at the bottom of
the canister
8. Make sure there is clean water in the solution tank
9. Check that the tap lever is fully opened, the lever is positioned at the rear of the machine.
10. Verify that the bypass tap is in the "dosing system" position
11. Turn the water flow adjustment knob (4) to its maximum position
12. Turn the detergent percentage adjustment knob (5) to its maximum position
13. Connect the battery connector to the machine connector.
14. Set the main switch to the "ON – I" position
15. Disengage the parking brake
16. Lower the brush head body by means of the pedal (6)
17. Activate the dead man's levers (7) to allow the operation of the brush head and the dosing system
18. Wait a few moments keeping the dead man's levers pressed (normally 20 to 40 seconds) to allow the
insertion of the system
19. Proceed with the desired adjustment for normal cleaning
WARNING: During this operation the machine will deliver the solution
MACHINE PREPARATION
23
1
2
1
3
5
7
6
4
