8. Disconnect the electrical system connector from the battery connector (2)
9. Connect the battery charger connector to the electrical system connector
The coupling connector of the battery charger is consigned inside the bag containing this instruction
booklet, and must be assembled on the cables of the battery charger as indicated in the instructions.
ATTENTION: this process must be carried out by qualified personnel. An
incorrect connection of the connector may cause problems with machine
functioning.
10. Connect the recently wired cable to the external battery charger
ATTENTION: Carefully read the use and maintenance instructions of the
battery charger that is used for charging.
ATTENTION: Keep the recovery tank open for the duration of the battery
recharging
to allow gas fumes to escape
11. After the charging cycle is complete, the battery connector (2) must be connected to the electrical
system connector
ATTENTION: danger of exhalation of gas and leakage of corrosive liquids
ATTENTION: danger of fire: do not go near with free flames
11.

CHARGING THE BATTERIES WITH A BUILT-IN BATTERY CHARGER

In order not to cause permanent damage to the batteries it is essential to avoid their complete discharge:
arrange the recharge within a few minutes of the switching on of the flashing "discharged batteries" signal.
ATTENTION: never leave the batteries completely discharged, even if the
machine is not being used. Check the battery charger is suitable for the
batteries installed, in terms of both capacity and type.
To connect the internal battery charger you must:
1. Make sure the recovery tank is empty, otherwise empty it completely
2. Make sure that the key switch in the "0" position
3. Move the machine near to the battery charger
4. Lower the squeegee and brush head (see the appropriate chapters)
5. Engage the parking brake (see the appropriate chapter)
6. Open the rear hinge that closes the upper tank (1)
7. Rotate the tank as far as it will go, using the side handle (2)
MACHINE PREPARATION
13
2
cycle
2
1
