Electrical
• Operates between 100V and 240VAC at a frequency of 50/60Hz.
• Maximum power consumption:
- Linear 1: 120W
- Linear 2: 240W
- Linear 4: 480W
• Up to 9 cells (0.5 m segments) may be linked via power thru connector.
• Up to 10 cells (0.5 m segments) total per circuit when used with an
R20 Relay Module or Unison Echo
curves when used with other equipment. Requires power from a non-
dimmable source.
• Inrush (Linear 1/Linear 2/Linear 4):
- 120V: 35A/35.6A/67.5A (first half-cycle)
- 240V: 49A/85.6A/153A (first half-cycle)

Typical power consumption

Linear 1
Idle Power/Current
Direct at Full/Current
Linear 2
Idle Power/Current
Direct at Full/Current
Linear 4
Idle Power/Current
Direct at Full/Current
ColorSource Linear v1.7
100V
1.63W/0.03A
107W/1.07A
100V
2.86W/0.06A
210.83W/2.12A
100V
5.28W/0.11A
424.17W/4.27A
Page 3 of 20
®
Relay Panel. Consult breaker trip
120V
1.55W/0.03A
105W/0.88A
120V
2.98W/0.06A
208.67W/1.75A
120V
5.24W/0.11A
419.33W/3.52A
230V
1.43W/0.03A
104W/0.46A
230V
2.56W/0.06A
204.5W/.91A
230V
4.65W/0.12A
409.17W/1.82A
