ETC Installation Guide
ColorSource CYC v1.6
Environment
The ColorSource CYC operates in ambient temperatures of 0°C–40°C.
Note: The ColorSource CYC is for indoor use only.
Note: • Maximum recommended ambient operating
Electrical
• Operates between 100V and 240VAC at a frequency of 50/60Hz.
• Maximum power consumption is 160W.
• Up to 9 luminaires (15A max) may be linked via power thru connector
(10 luminaires total per circuit) when used with an R20 Relay Module
or Unison Echo
with other equipment. Requires power from a non-dimmable source.
• Inrush:
- 120V: 39A (first half-cycle)
- 240V: 74A (first half-cycle)

Typical power consumption

Idle Power/Current
Direct at Full/Current
ColorSource CYC v1.6
temperature: Ta = 40°C (104°F)
• Maximum anticipated external surface temperature
at 40°C ambient: Tmax = 110°C (230°F)
• External temperatures after 5 minutes of full-
brightness operation at 25°C (77°F) ambient:
49°C (119°F)
• External temperature (steady state achieved) at
25°C (77°F): 88°C (190°F)
®
Relay Panel. Consult breaker trip curves when used
100V
1.66W/0.0414A
133.7W/1.34A
Page 2 of 12
120V
1.38W/0.04A
132.6W/1.11A
230V
1.18W/0.0486A
130.4W/0.594A
