Using RDM

RDM and Grouping modes
Linear 2 and Linear 4 fixtures in Cell mode contain 2 sub-devices (Linear 2) or
4 sub-devices (Linear 4). Use DMX_BLOCK_ADDRESS to set the DMX address
of the first cell, and the remaining cells will be numbered sequentially from
that starting value.
RDM also allows you to use nonsequential DMX addresses, if desired. The
fixture displays "---" for the DMX address to indicate nonsequential DMX
addressing. If you set up nonsequential DMX addresses and then change the
DMX address at the fixture, however, the fixture will return to sequential
DMX addressing.
Linear 2 and Linear 4 fixtures in Group mode do not use sub-devices.
RDM Values
Manufacturer ID: 0x6574 (Electronic Theatre Controls)
Model ID:
• Linear 1: 0x0209 (ETC ColorSource Linear 1) or
0x020A (ETC ColorSource Linear 1 Deep Blue)
• Linear 2: 0x020D (ETC ColorSource Linear 2) or
0x020E (ETC ColorSource Linear 2 Deep Blue)
• Linear 4: 0x0211 (ETC ColorSource Linear 4) or
0x0212 (ETC ColorSource Linear 4 Deep Blue)
Parameter
DMX Start
Address
Personality ID
Output
Frequency
ColorSource Linear v1.7
RDM PID Fixture
0x00F0 All
Linear 1;
Linear 2 and
Linear 4 in
Group mode
0x00E0
Linear 2 and
Linear 4 in
Cell mode
Linear 1;
Linear 2 and
0x8123
Linear 4 in
Group mode
Page 17 of 20
Value
Range = 1–512
1 = 5 Channel
2 = Direct
3 = 1 Channel
4 = RGB
5 = 5 Channel Multi-Cell
6 = Direct Multi-Cell
7 = 1 Channel Multi-Cell
8 = RGB Multi-Cell
0 = Standard (1.2 kHz)
1 = High (25 kHz)
