Press Exit to return to the Configuration Menu.
8)
Select and press Enter to return to the Main Menu.
9)
If the MultiLoad II/ RCU II has a Program/Weights and Measures switch, return the switch to
10)
Operating Mode.
6.6 Verifying Communications between MultiLoad II/ RCU II and I/O Board
Enter program mode by pressing 00000 on the keypad, then press Next key.
1)
Select diagnostics from main menu:
2)
D I A G N O S T I C S
Card Reader
COM Loopback
Serial Ports
PTB Serial –Test
Network Test
Keypad
Display
Unicode
FCM Com
PCM Com
FCM Health
PCM Health
RCU
Bay
Next Prev
MultiLoad II
For MultiLoad II, select FCM COM. For RCU II, select RCU:
3)
000 FCM COM DIAGNOSTICS
00-Ok
MultiLoad II
If screen displays "00-OK" (or "I/O Board Com: OK" for the RCU II), the I/O board is communicating
4)
with the MultiLoad II or RCU II.
If the I/O board is not communicating the message "00-ERR" appears (or "I/O Board Com: ERR" for
5)
the RCU II).
M E N U
Preset
Meters
Components
Additives
Sampler
Custom Logic
Modbus Device
Thread Info
SD Card
Exit Enter
Exit
D I A G N O S T I C S
Card Reader
COM Loopback
Serial Ports
Network Test
Keypad
Display
Unicode
RCU
Next Prev
RCU II
RCU I/O DIAGNOSTICS
I/O Board Com: Ok
Timeouts: 000000003
[1]AC Output 0 - OFF
[2]AC Output 1 - OFF
[3]AC Output 2 - OFF
[4]AC Output 3 - OFF
[5]AC Output 8 - OFF
[6]DC Output 10 – OFF
[6]DC Output 11 – OFF
[6]DC Output 12 – OFF
Exit
RCU II
M E N U
Exit Enter
F/W Rev: 033
Com Lost: 000000001
DC Input 4 – OFF
DC Input 5 – OFF
DC Input 6 – OFF
DC Input 7 – OFF
DC Input 9 – OFF
Counter 4 - 00000
Counter 5 - 00000
Program Key– OFF
W&M Key – OFF
Battery @ 36C 3.24V
Battery 100%
Clear
