L A B E L I C O N C O L O U R
Green A USB device is connected.
Green Data is being transmitted through the USB interface.
USB
Blinking
Off No USB device is connected to the USB interface.
Green A handset is registered.
1
Green Incoming call or the handset is in use.
Telephone
Blinking
2
Off No handset registered
VDSL/ADSL2+ Dual Band AC1600 Gigabit Gateway with VoIP – NF18ACV
UG01040 v 1.04 December 2018
D E F I N I T I O N

Rear view

The following interfaces are available on the rear panel of the NF18ACV:
Figure 1 – NF18ACV router rear view
N O . I N T E R F A C E
1 DSL Use the provided RJ11 cable to connect the router to the
telephone line operating your xDSL service.
2 Telephone 1 and Connect a regular analogue telephone handset here for use with
2 a VoIP service.
3 Ethernet 1 - 4 Gigabit Ethernet LAN ports. Connect your Ethernet based
devices to one of these ports for high-speed internet access.
D E S C R I P T I O N
