Phone – SIP Settings – continued
VDSL/ADSL2+ Dual Band AC1600 Gigabit Gateway with VoIP – NF18ACV
UG01040 v 1.04 December 2018
I T E M
Digitmap Setting The VoIP Dialplan specifies how to interpret digit sequences dialled by the user, and how to
convert those sequences into an outbound dial string.
QoS Setting
DSCP for SIP Select a specific Differentiated Services Code Point (DSCP) setting for SIP or accept the
default: DEFAULT(00000)
DSCP for RTP Select a specific Differentiated Services Code Point (DSCP) setting for RTP or accept the
default: DEFAULT(00000)
Ethernet Priority Mark The default is: –1
Payload Setting
RFC2198 Payload Value Enter a value between 97 to 127, or accept the default of 125
Dtmf Relay setting Select an appropriate Dual-tone Multi-frequency Relay Settings: InBand (default, used when
the other two are not available), RFC2833 or SIPInfo
Call ID Setting
Caller ID send Delay Time Enter a value in milliseconds (ms) between 500 to 1500ms, or accept the default of 600ms
Caller ID Message Type Select a Caller ID Message Type: FSK_SDMF, FSK_MDMF or DTMF
FSK modulation Mode Select the optimal Frequency-shift keying modulation mode: BellcoreGen, V23Gen or V23UK
Transport Setting Select the appropriate SIP Transport protocol: UDP or TCP
SIP Extends Select the appropriate PRACK (100rel) setting: Supported (default), Disabled or Required
Service Offer Setting Select your Complementary business model: Local, Server, IMS or undefined
Apply button Click to apply the new settings.
D E F I N I T I O N
