NetComm Wireless NF17ACV Setup Manual

Enhanced vdsl/adsl wireless ac1600 gigabit gateway remote administration setup guide

Remote Administration Overview

Remote administration allows you to access the NF17ACV web User Interface from a remote computer connected to the

internet.

This can also be used to enable your ISP (Internet Service Provider) to check your settings if you experience connection

issues.

Before enabling remote access to your NF17ACV, we recommend changing the username and password required to login.

Please refer to the Change Administration Password Guide document for assistance with this. You can also limit access to a

specific IP or subnet. This will prevent unauthorized access to your NF17ACV.

Open a web browser (such as Internet Explorer, Google Chrome or Firefox), type

bar and press Enter.

At the login screen, type

From the Management menu on the left, then select Access Control and then Services Control from the sub menu.

NF17ACV FAQs

Remote Administration Setup Guide

admin

into both the User Name and the Password fields and click OK or Log In.

NF17ACV FAQs

http://192.168.20.1

into the address

1 of 4

Table of Contents

Do you have a question about the NF17ACV and is the answer not in the manual?

Page 1 NF17ACV FAQs Remote Administration Overview Remote administration allows you to access the NF17ACV web User Interface from a remote computer connected to the internet. This can also be used to enable your ISP (Internet Service Provider) to check your settings if you experience connection issues.
Page 2 You should now be able to access your NF17ACV locally, via the address: http://<your LAN IP address>:<port number> You should now be able to access your NF17ACV from internet, via the address: http://<your WAN IP address>:<port number> You can find your external (public) IP address by going to www.ipmonkey.com or by clicking on WAN option under Device Info.
Page 3 Restricting Remote Administration to a Particular IP Address(es) Apart from changing the default admin password and web port, you may secure your NF17ACV by configuring which IP address or addresses can remotely access it. You can configure either a single IP address or a block of addresses to be allowed access.
Page 4 Now only that IP address (or range of IP Addresses) can remotely access your NF17ACV’s web interface. However, you always can configure it through its web interface from a local LAN.
