Queue
Open the Advanced menu and click the Queue
I T E M
Name Add a meaningful name so that you can readily identify the queue..
Key System-generated sequential reference number.
interface Select an interface for the queue. Options include: LAN1~4 or eth4(wan)
Qid Indicates the priority of the queue for the selected interface.
Prec/Alg/Wght Indicates the Precedence , Algorithm and Weight used for calculating the priority of the queue.
DSL Latency Path0(fast) or Path1(interleaved). This is selected while creating Interface,. The default is: Path0
PTM Priority Defines how PTM traffic packets should be handled. During congestion High priority traffic gets priority over Lower.
Shaping Rate (bps) The speed you would limit the queue to in bps (bits per second) after the burst size.
Burst Size (bytes) Set a maximum size for traffic to be sent in.
Add button To create a new queue, click the Add button and define the queue in the Add Queue window, see next page.
Enable button
Unselect Enable to disable the application of a queue rule without deleting it from the list.
You can then later
Delete Button To permanently remove a queue rule click the Delete button. You will be not be prompted to confirm this action.
View Wlan Queue Setup Click to open the View WLAN Queue Setup page, see next page.
VDSL/ADSL2+ Dual Band AC1600 Gigabit Gateway with VoIP – NF18ACV
UG01040 v 1.04 December 2018
link in the QoS section.
D E F I N I T I O N
Enable the queue rule without needing to redefine it.
Number of Queues
The maximum number of queues that can be
defined depends on the type of connection:
•
In ATM mode, a maximum of 16 queues
can be configured.
• In PTM mode, a maximum of 8 queues
can be configured.
•
For each Ethernet interface, there is a
maximum of 4 queues that can be
configured.
•
For each Ethernet WAN interface, there
is a maximum of 8 queues that can be
configured.
