NetComm Wireless NF18ACV User Manual page 41

The second group displays details of the current status of your WAN connection.
I T E M
Line Rate – Upstream (Kbps) The current synchronisation upstream speed of the
DSL connection in Kbps (Kilobits per second).
Line Rate – Downstream (Kbps) The current synchronisation upstream speed of the
DSL connection in Kbps (Kilobits per second).
LAN IPv4 Address The current IPv4 LAN IP address assigned to the
router.
Service connection type Displays whether the WAN connection is
ADSL/VDSL or Ethernet WAN.
Default Gateway The current default gateway address of the WAN
interface.
Primary DNS Server The current primary DNS server in use
Secondary DNS Server The current secondary DNS server is use.
LAN IPv6 ULA Address The current IPv6 LAN IP address in use if assigned.
Default IPv6 Gateway The current IPv6 default gateway if assigned.
Date/Time The current local date and time set on the router.
VDSL/ADSL2+ Dual Band AC1600 Gigabit Gateway with VoIP – NF18ACV
UG01040 v 1.04 December 2018
D E S C R I P T I O N
WAN
Further down on the page the WAN table shows more detailed information related to the WAN
interface configuration, including the firewall status, IPv4 and IPv6 addresses of the router.
I T E M
Interface The Interface of the WAN connection.
Description The description of the WAN connection.
Type The type of WAN connection.
VLAN Mux ID Details the status of VLAN Mux ID, if used.
IPv6 The status of IPv6.
IGMP Pxy Details the status of IGMP on each WAN connection.
IGMP is only used with IP v4 connections.
IGMP proxy enables the router to issue IGMP host messages on behalf of hosts
that the router discovered through standard IGMP interfaces, allowing NAT
transversal of Multicast traffic.
IGMP Source Details the status of IGMP Src on each WAN connection.
Enable
IGMP Sources function send a membership report that includes a list of IGMP
source addresses.
MLD Pxy Shows the status of the Multicast Listener Discovery protocol when IPv6 is in use.
Multicast Listener Discovery (MLD) proxy enables the router to issue MLD host
messages on behalf of hosts that the router discovered through standard MLD
interfaces.
D E F I N I T I O N
© NetComm Wireless 2018
41 of 93
