Remote Administration Overview

Remote administration allows you to access the NF18ACV web User Interface from a remote computer connected to the

internet.

This can also be used to enable your ISP (Internet Service Provider) to check your settings if you experience connection

issues.

Before enabling remote access to your NF18ACV, we recommend changing the username and password required to login.

Please refer to the Change Administration Password Guide document for assistance with this. You can also limit access to a

specific IP or subnet. This will prevent unauthorized access to your NF18ACV.

Open a web browser (such as Internet Explorer, Google Chrome or Firefox), type

bar and press Enter.

At the login screen, type

From the Management menu on the left, then select Access Control and then Services Control from the sub menu.

NF18ACV FAQs

Remote Administration Setup Guide

admin

into both the User Name and the Password fields and click OK or Log In.

NF18ACV FAQs

http://192.168.20.1

into the address

1 of 4

Table of Contents

Do you have a question about the NF18ACV and is the answer not in the manual?

Page 1 NF18ACV FAQs Remote Administration Overview Remote administration allows you to access the NF18ACV web User Interface from a remote computer connected to the internet. This can also be used to enable your ISP (Internet Service Provider) to check your settings if you experience connection issues.
Page 2 Click the Apply/Save button. You should now be able to access your NF18ACV via the address: http://<your external IP address>:<port number> You can find your external (public) IP address by going to www.ipmonkey.com or by clicking on WAN option under Device Info.
Page 3 Restricting Remote Administration to a Particular IP Address(es) Apart from changing default admin password and web port, you may secure your NF18ACV by configuring which IP address or addresses can remotely access. You can configure either a single IP address or a block of addresses to be allowed access.
Page 4 Now click on the  Enable radio button to enable the access control. Once clicked the settings will be applied automatically, you do not need to press any other button to enable it. Now only that IP address (block) can access your NF18ACV’s web interface. However, you always can configure through web interface from local LAN.
