PHONE

VDSL/ADSL2+ Dual Band AC1600 Gigabit Gateway with VoIP – NF18ACV
UG01040 v 1.04 December 2018
To connect a phone you will need to use the Tel 1 / Tel 2 ports located at the back of the router. You can have up to two phone lines each separately
defined in the device's configuration. You can connect a standard or cordless phone directly into the RJ11 ports. Your ISP will generally pre-
configure TEL 1 port to work as the primary telephone port so it connects to their phone network. Your ISP will supply you with your phone number.
If the device is not pre-configured then you will have to get the SIP details from your ISP and enter them into the form illustrated here.
If the configuration is correctly set up and the router is connected to the internet then the phone should work as soon as its plugged in.
I T E M
SIP Username The username as defined by your ISP
SIP Password The password supplied by your ISP
Line Number The telephone number supplied by your ISP.
Click the More Settings button to show additional settings for the selected line.
I T E M
SIP Proxy The IP address of the proxy.
SIP Proxy Port The port that this proxy is listening on. By default, the port value is 5060.
SIP Registrar Enter the IP address of the SIP registrar.
SIP Registrar Port The port that SIP registrar is listening on. By default, the port value is 5060.
SIP Outbound Proxy
Click
This is an additional proxy, through which all outgoing calls are directed. In some cases, the outbound proxy is
placed alongside the firewall and it is the only way to let SIP traffic pass from the internal network to the Internet.
SIP Outbound Proxy Enter the IP address of the outbound proxy.
SIP Outbound Proxy Port The port that the outbound proxy is listening on.
By default, the port value is 5060.
Show / Hide buttons For additional Advanced Calling Features that may be supported by your ISP, click
Apply button Click to save and apply any changes.
Enable if your network service provider requires the use of an outbound proxy.
D E S C R I P T I O N
D E S C R I P T I O N
Show. See next section.
