I T E M
Use Interface The interface type to be used by the rule.
Service Name Enter a descriptive name for the service that the rule will apply to.
LAN Loopback Select Enable to allow the LAN host to access another LAN host/server via the external
IP Address of the gateway.
When Disable is selected you must use the internal IP address of the device when on the
LAN side.
Server IP Address Enter the IP address of the local server/host.
Status Select Enable to allow the rule to be accessible.
Select Disable to save the rule in an inactive state.
External Port Start Enter the starting external port number range (when custom server is selected).
When a predefined service is selected this field will be completed automatically
External Port End Enter the ending external port number range (when custom server is selected).
When a predefined service is selected this field will be completed automatically.
Protocol The options are: TCP, UDP or TCP/UDP
Internal Port Start Enter the starting internal port number range (when custom server is selected).
When a predefined service is selected this field will be completed automatically.
Internal Port End Enter the ending internal port number range (when custom server is selected).
When a predefined service is selected this field will be completed automatically.
Apply/Save button Click to save and enable the rule.
Up to 32 rules can be defined.
D E F I N I T I O N
