Port Forwarding Overview

Port forwarding enables programs or devices running on your LAN to communicate with the internet as if they were directly

connected. This is most commonly used for remotely accessing DVR/NVR Controller, IP Cameras, Web Server or online

gaming (via game console or computer).

Port forwarding works by "forwarding" a specific TCP or UDP port from the NF10WV to the computer or device you are using.

Prior to setting the port forwarding function you must know which ports need to be opened. If you are not sure, contact the

application vendor or developer.

Open NF10WV Web interface

Open a web browser (such as Internet Explorer, Google Chrome or Firefox), type http://192.168.20.1 into the address

bar and press Enter.

At the login screen, type admin into both the User Name and the Password fields and click OK.

NF10WV FAQs

Port Forwarding Setup Guide

NF10WV FAQs

1 of 4

Table of Contents

Do you have a question about the NF10WV and is the answer not in the manual?

Page 1 This is most commonly used for remotely accessing DVR/NVR Controller, IP Cameras, Web Server or online gaming (via game console or computer). Port forwarding works by “forwarding” a specific TCP or UDP port from the NF10WV to the computer or device you are using. Prerequisite Prior to setting the port forwarding function you must know which ports need to be opened.
Page 2 Select the correct Interface in the Use Interface field as a misconfiguration will end up failing to forward anything. The correct interface can be checked from Device Info > WAN. If you have multiple entries, choose one with an available IPv4 address. 2 of 4 Port Forwarding Setup Guide © NetComm Wireless 2017...
Page 3 If you only want to open one port, then enter the same number in Start and End port fields, but if you want to open range of ports, then enter the start number in Port Start field and end number in Port End field. NF10WV FAQs 3 of 4 © NetComm Wireless 2017...
Page 4 Similarly, remote access and the webserver must have unique port numbers For example, you cannot host a web server accessible through port 80 of your public IP and enable remote http administration of the NF10WV through port 80, you must provide both with unique port numbers.
