4 Inserting and charging the rechargeable batteries

Figure 4: Battery compartment view of the device (plusoptiX S12C)

Attention:
If you need to put the device on its rear side, e.g. to insert or replace the
rechargeable batteries, please place a soft cloth under the device.
To insert the batteries, please put the device on a level working surface on its rear side.
Attention:
If you insert batteries other than those supplied, you should exclusively use
rechargeable Nickel Metal Hydride NiMH/AA HR6 batteries with a capacity of at
least 1900 mAh and a quick-charge rate of min. 1 A.
Now remove the battery compartment cover using a 1-cent coin, and insert the supplied
rechargeable batteries.
Note:
When inserting rechargeable batteries, please ensure that the contacts are
located on the correct side.
Note:
The type plate with the serial number (S/N 120xS-xxx-xxxx xxxx) is located under
the battery compartment. If you contact us regarding extended service or
warranty questions, please remember to always quote the serial number of your
device. The S/N number helps us to answer your question quickly.
Page 10/25
Battery
compartment
Type plate
