7.2

Ordering new Measurements

To order new measurements, we require certain information about your device. This
information can be found in the area "Loading Measurements" in the lower left area of the
Pay-Per-Use Management (see Figure 6).
Connect a SD card and activate the button to create the order fax (1). Confirm this with the
green tick (2), in order to save an order fax to the SD card. This contains all details
necessary for an order.
You can also have your address automatically printed on the order fax. Create a text file with
a maximum of 5 lines and name it "surgeryaddress.txt". Copy the file to the directory "/db" of
a USB stick. As soon as you connect the USB stick to the running "plusoptiX S12", your
address is loaded automatically. After loading, the text file is automatically deleted on the
USB stick. To overwrite the stored address, a new text file must merely be saved in the
directory "/db" of the USB-memory stick.
You can:
- send the order fax per mail to the mail address specified on the order fax.
- print out the order fax on your network- or workplace printer and send it per fax to the fax
number specified on the order fax. To do this you must first open the PDF file of the order
fax from your workplace computer. There are two different access possibilities available:
Connect SD card stick directly to the workplace computer.
Start Windows Explorer or Apple Finder and open the order fax to be printed.
You can print out the order fax on any optional printer connected with your
network- or workplace computer.
Manual network access (WLAN)
File access at URL:
The place holder "xxxx" stands for the last four digits of the serial number.
If the workplace computer indicates the error message "Access denied",
restart Windows Explorer or Apple Finder.
Note:
The saving of the order fax takes a few seconds and is dependent on the SD
card. If the SD card is removed too soon or the URL called up too early, the PDF-
file is not yet saved.
If the SD card has been removed too soon, it must be plugged into the "plusoptiX
S12" again, in order to save the order fax on the SD card.
If accessed too early, the URL must be called up again.
Plusoptix will then send you a load code, with which you can load your credits. Enter this
load code in the gray field "Load Code" (3) using the keypad integrated in the screen view or
with the help of a connected USB keyboard (see chapter 3.3 "Connection the USB keyboard
and mouse (optional)") and then confirm this with the green tick (2) in the navigation bar. The
new measurements will be immediately displayed in the field "Loaded" and at the right in the
header.
\\px12-xxxx\pdf (Windows Explorer)
smb://px12-xxxx/pdf (Apple Finder)
1) 2) 3)
Page 14/25
