3.2.

Mini USB interface

Attention:
To avoid damage to the device, do not connect any external devices other than an
IEC 60601-1-approved computer to the mini-USB interface.
The device features a 5-pole-Mini-B-USB port. This is used by Plusoptix as part of the
production process and in the case of a service and warranty issue. The connection over a
Mini-USB cable is available for all S12 devices from the supplement "01F" in the serial
number (Example: S/N 120xS-01F-xxxx xxxx). Because of the technical design, devices with
older serial numbers are not compatible.
It can be used to connect the device to your workplace computer. The device is portrayed as
removable medium in your Windows-Explorer or Apple Finder.
Note:
All interfaces are installed upside down. Therefore all connectors must also be
turned around before being inserted (i.e. USB symbol faces downwards).
The connection with Mini-USB is used for:
- Printing a screening report (PDF file)
URL: removable medium:\pdf
- Download Software Updates
Note:
To use the Mini-USB interface the WLAN interface must be deactivated. If there is
an active WLAN connection, the Mini-USB interface is deactivated.
3.3.

Connection the USB keyboard and mouse (optional)

To ease patient data entry on the "plusoptiX S12", it is necessary to connect a conventional
USB keyboard. Connect your input device with the USB interface of the "plusoptiX S12". You
can also connect wireless input devices instead of cabled ones.
If a connected mouse or keyboard is not working, please check whether the USB keyboard
or mouse is switched on, connected with the "plusoptiX S12" and whether the batteries are
inserted. If your input device still doesn't work, this means it is not supported by the drivers
installed in the "plusoptiX S12". Use input devices from another manufacturer instead in this
case.
Note:
Non-functioning external input devices do not constitute a service or warranty
case!
Page 9/25
