After inserting the rechargeable batteries, close the battery compartment cover and place the
device in front of you. Now connect the medical power adapter with its power cable to the
wall socket and check whether voltage is present (green light diode at the top of the medical
power adapter lights up). Then connect the 12V charging cable of the medical power adapter
to the device.
The inserted rechargeable batteries will now be charged automatically. The charging time of
the batteries depends on the charge level of the batteries. The maximum battery charging
time is 3 hours for the supplied rechargeable batteries.
5 Putting the „plusoptiX S12" into operation and adjusting
settings
Press the On / Off button briefly to turn the device on. The screen will come on immediately
and the "plusoptiX S12" will start up. After approx. 25 seconds, the "plusoptiX S12" is ready
to operate. After inserting the batteries, the date and time settings page is displayed on the
screen.
Setting the date
button
The selected time and date format is highlighted (1). Using the orange arrows (2), set the
right date and current time. Confirm your entries with the green checkmark (3). The date,
time and display format can be changed at a later date in the settings (4).
Press the On / Off button briefly to turn the device off. The "plusoptiX S12" will turn off.
More information about adjusting the settings and implementing a WLAN connection can be
found in short manual 1 on our homepage (www.plusoptix.com), under support.

Figure 5: Setting the date and time

1) 2)
Page 11/25
3) 4)
Time format
buttons
Date format
buttons
Setting the time
button
