PLUSOPTIX S12C User Manual page 23

Emissions Test
RF Emission CISPR 11
RF Emission CISPR 11
Harmonic Emissions
IEC 61000-3-2
Voltage fluctuations /
Flicker IEC 61000-3-3
Immunity Test IEC 60601 test values
± 8 kV contact
ESD IEC 61000-4-2
± 2, 4, 8, 15 kV air
Electrical fast
transient / burst ± 2 kV
IEC 61000-4-4
± 0.5 kV
Surge
± 1 kV
IEC 61000-4-5
± 2 kV
0% 0.5 cycles
Voltage dips, short
@ 0°, 45°, 90°, 135°,
interruptions on
180°, 225°, 270°, 315°
power supply input
0% 1 cycle
lines IEC 61000-4-
70% 25 cycles
11
0% 250
Power frequencies
and magnetic fields 30 A/m, 50/60Hz
IEC 61000-4-8
Conformity Electromagnetic environment - Instructions
The radiation is low and causes no interferences with
Group 1
electronic devices found nearby.
Category B
The "plusoptiX 12" can be used in all areas which are
Category A
connected to the public mains supply.
Complies
Conformity values
± 8 kV contact
± 2, 4, 8, 15 kV air
± 2 kV
± 0.5 kV
± 1 kV
± 2 kV
0% 0.5 cycles
@ 0°, 45°, 90°, 135°,
180°, 225°, 270°, 315°
0% 1 cycle
70% 25 cycles
cycles 0% 250 cycles
30 A/m, 50/60Hz
Seite 23/25
Electromagnetic
environment -
Instructions
The floor should be
made of wood, ceramic
or stone. If the floor is
covered with a
synthetic material, the
relative air humidity
should not be less than
30%.
Only plugs that are
usually available in
domestic or clinical
areas should be used.
Only plugs that are
usually available in
domestic or clinical
areas should be used.
Only plugs that are
usually available in
domestic or clinical
areas should be used.
Magnetic fields should
not exceed the usual
areas.
