Robustel MEG5000 User Guide
2.3

LED Indicators

Name Color
RUN Green
MODEM Green
USR-SIM Green
USR-NET Green
USR-WiFi Green
RT_UG_MEG5000_v.1.0.3
Status
On, fast blinking
(250 mSec blink time)
On, blinking
(500 mSec blink time)
Off
On, solid
Off
On, blinking
Off
On, solid
On, blinking
Off
On, solid
On, blinking
Off
Description
Gateway is powered on
(System is initializing)
Gateway starts operating
Gateway is powered off
Link connection is working
Link connection is not working
Backup card is being used
Main card is being used
Network is joined successfully and worked in an optimum
one
Network is joined successfully but worked in a lower-level
than standard
Network is not joined or joining
WiFi is enabled and working properly
Data is sent and received via WiFi port.
WiFi is disabled or not working properly
12 Dec, 2018 18/150
