- Page 1 EG9012 KONE Connection 210 (North America) For 3G/4G Networks User Guide...
- Page 2 The contents of this document are subject to change without notice due to continued progress in methodology, design and manufacturing. Robustel shall have no liability for any error or damage of any kind resulting from the use of this document.
- Page 3 Robustel accepts no responsibility for damages of any kind resulting from delays or errors in data transmitted or received using the gateway, or for failure of the gateway to transmit or receive such data.
- Page 4 Robustel EG9012 User Guide Protecting Your Gateway To ensure error-free usage, please install and operate your gateway with care. Do remember the following: Do not expose the gateway to extreme conditions such as high humidity / rain, high temperature, direct sunlight, ...
- Page 5 Robustel EG9012 User Guide Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 6 Robustel EG9012 User Guide Industry Canada statement This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: this device may not cause interference, and this device must accept any interference, including interference that may cause undesired operation of the device.
- Page 7 Robustel EG9012 User Guide Regulatory and Type Approval Information Table 1: Directives 2011/65/EC Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and...
- Page 8 Robustel EG9012 User Guide Document History Updates between document versions are cumulative. Therefore, the latest document version contains all updates made to previous versions. Date Firmware Version Doc Version Change Description 25 April, 2017 0.10.2 v.1.0.0 Initial release 2 June, 2017 0.11.2...
-
Page 9: Table Of Contents
Robustel EG9012 User Guide Contents Chapter 1 Product Concept ........................... 10 Key Features ............................. 10 Package Contents ............................. 11 Specifications ............................11 Ordering Information ..........................12 Dimensions ............................... 13 Chapter 2 Hardware Installation ........................14 LED Indicators ............................14 PIN Assignment ............................15 Ethernet Ports ............................ -
Page 10: Chapter 1 Product Concept
Robustel EG9012 User Guide Chapter 1 Product Concept 1.1 Key Features Robustel EG9012 is an industrial gateway designed for monitoring and provides fast, reliable and stable Internet connectivity. EG9012 is a powerful gateway developed from RobustOS, a Robustel self-developed and Linux-based operating system which designed to be used in Robustel hardware gateways. -
Page 11: Package Contents
1 x Robustel EG9012 KONE Connection 210 (North America) 35 mm DIN rail mounting kit Note: If any of the above items is missing or damaged, please contact your Robustel sales representative. 1.3 Specifications Cellular Interface Standards: W-CDMA/FDD-LTE/TDD-LTE ... -
Page 12: Ordering Information
Robustel EG9012 User Guide Interface: 3.81mm connector Audio Interface Physical Connector: 3.81mm 3-PIN terminal block Interface type: FXS Interface Standard: ITU Q.512 (SLIC), ITU K.20 (overcurrent and overvoltage protection) Subscriber line interface circuit (SLIC) Ring voltage: 40~90 Vpk configurable... -
Page 13: Dimensions
Robustel EG9012 User Guide Extended Operating Temperature: -40~-30°C, +70~+85°C Humidity: 5~95%RH 1.5 Dimensions RT_UG_EG9012_v.1.0.1 2 June, 2017 13/22 Confidential... -
Page 14: Chapter 2 Hardware Installation
Robustel EG9012 User Guide Chapter 2 Hardware Installation 2.1 LED Indicators Name Color Status Description Green Gateway is powered on DEV1 Green Connected to controller1 DEV2 Green Connected to controller2 Green Always On Connected to 4G network Blinking every 100ms... -
Page 15: Pin Assignment
Robustel EG9012 User Guide 2.2 PIN Assignment There are terminal block PIN relationship tables on the front view of the EG9012, as the following figure showed. XRS4 (Debug) Function Direction Device EG9012 EG9012Device Top View XIT (FXS) Function Direction RING Device... -
Page 16: Ethernet Ports
Robustel EG9012 User Guide 2.3 Ethernet Ports Bottom View Ethernet Ports Each Ethernet port has two LED indicators (please check the picture above). The yellow one is Speed indicator and the green one is Link indicator. There are three status of each indicator. For details please refer to the form below. -
Page 17: Insert Or Remove Sim Card
Robustel EG9012 User Guide 2.4 Insert or Remove SIM Card Be sure to insert a SIM card before you use the gateway. Insert or remove the SIM as shown in the following steps. Inserting SIM Card Power off the gateway. -
Page 18: Attach External Antenna (Sma Type)
Robustel EG9012 User Guide 2.5 Attach External Antenna (SMA Type) Attach an external SMA antenna to the gateway’s connector and twist tightly. Make sure the antenna is within the correct frequency range provided by the ISP and with 50 Ohm impedance. -
Page 19: Mount The Gateway
Robustel EG9012 User Guide 2.6 Mount the Gateway The gateway can be mounted a 35 mm DIN rail. DIN rail size (measured in mm) Use 3 pcs of M3*6 flat head Phillips screws to fix the DIN rail to the gateway, and then hang the DIN rail on the mounting bracket. -
Page 20: Ground The Gateway
Ground Screw Bottom View 2.8 Connect the Gateway to a Computer Connect an Ethernet cable to LAN1 or LAN2 at the bottom of the EG9012, and connect the other end of the cable to your computer. RT_UG_EG9012_v.1.0.1 2 June, 2017... -
Page 21: Power Supply
Robustel EG9012 User Guide 2.9 Power Supply EG9012 Gateway supports reverse polarity protection, but always refers to the figure above to connect the power adapter correctly. Note: The range of power voltage is 9 to 26V DC. RT_UG_EG9012_v.1.0.1 2 June, 2017... - Page 22 Robustel EG9012 User Guide Guangzhou Robustel Technologies Co., Ltd. Address: 3rd Floor, Building F, Kehui Park, No.95 Daguan Road, Guangzhou, China 510660 Tel: 086-20-29019902 Email: info@robustel.com RT_UG_EG9012_v.1.0.1 2 June, 2017 22/22 Confidential...
