Mechanical Installation

3.2.4.3 Inverter, Enclosure Sizes F12 and F13

3 3
FASTENER TORQUE: MIO 19 Nm (14 FT -LB)
U/T1 96 V/T2 97 W/T3 98
Illustration 3.13 Terminal Locations - Left, Front and Right Views. The gland plate is 42 mm below .0 level.
1) Ground bar
18
Operating Instructions
1
FASTENER TORQUE: MIO 19 Nm (14 FT -LB) FASTENER TORQUE: MIO 19 Nm (14 FT -LB)
U/T1 96 V/T2 97 W/T3 98 U/T1 96 V/T2 97 W/T3 98
Danfoss A/S © Rev. 06/2014 All rights reserved.
2
6
3
4
308.3 [12.14]
253.1 [9.96]
180.3 [7.10]
5
0.0 [0.00]
4
MG20Y202
