Troubleshooting
ALARM 95, Broken belt
Torque is below the torque level set for no load, indicating
a broken belt. 22-60 Broken Belt Function is set for alarm.
Troubleshooting
•
Troubleshoot the system and reset the frequency
converter after the fault has been cleared.
ALARM 96, Start delayed
Motor start has been delayed due to short-cycle
protection. 22-76 Interval between Starts is enabled.
Troubleshooting
•
Troubleshoot the system and reset the frequency
converter after the fault has been cleared.
WARNING 97, Stop delayed
Stopping the motor has been delayed due to short -cycle
protection. 22-76 Interval between Starts is enabled.
Troubleshooting
•
Troubleshoot the system and reset the frequency
converter after the fault has been cleared.
WARNING 98, Clock fault
Time is not set or the RTC clock has failed.
Troubleshooting
•
Reset the clock in 0-70 Date and Time.
ALARM 220, Overload trip
Motor overload has tripped. Indicates excess motor load.
Troubleshooting
•
Check motor and driven load.
•
To reset, press [Off Reset].
•
Then, to restart the system press [Auto on] or
[Hand on].
ALARM 243, Brake IGBT
This alarm is only for enclosure size F frequency converters.
It is equivalent to Alarm 27. The report value in the alarm
log indicates which power module generated the alarm:
1 = Left most inverter module.
2 = Middle inverter module in enclosure sizes F12
or F3.
2 = Right inverter module in enclosure sizes F10
or F11.
2 = Second frequency converter from the left
inverter module in enclosure size F14.
3 = Right inverter module in enclosure sizes F12
or F13.
3 = Third from the left intverter module in
enclosure size F14.
4 = Far right inverter module in enclosure size
F14.
5 = Rectifier module.
6 = Right rectifier module in enclosure size F14.
MG20Y202
Operating Instructions
ALARM 244, Heat Sink temperature
This alarm is only for enclosure type F frequency
converters. It is equivalent to Alarm 29. The report value in
the alarm log indicates which power module generated
the alarm:
ALARM 245, Heat Sink sensor
This alarm is only for enclosure size F frequency converters.
It is equivalent to Alarm 39. The report value in the alarm
log indicates which power module generated the alarm:
ALARM 246, Power card supply
This alarm is only for enclosure size F frequency converters.
It is equivalent to Alarm 46. The report value in the alarm
log indicates which power module generated the alarm:
Danfoss A/S © Rev. 06/2014 All rights reserved.
1 = Left most inverter module.
2 = Middle inverter module in enclosure size F12
or F3.
2 = Right inverter module in enclosure size F10
or F11.
2 = Second frequency converter from the left
inverter module in enclosure size F14.
3 = Rght inverter module in enclosure sizes F12
or F13.
3 = Tird from the left intverter module in
enclosure size F14.
4 = Far right inverter module in enclosure sizes
F14.
5 = Rectifier module.
6 = Right rectifier module in enclosure sizes F14.
1 = Left most inverter module.
2 = Middle inverter module in enclosure sizes F12
or F13.
2 = Right inverter module in enclosure sizes F10
or F11.
2 = Second frequency converter from the left
inverter module in enclosure size F14.
3 = Right inverter module in enclosure sizes F12
or F13.
3 = Third from the left inverter module in
enclosure size F14.
4 = Far right inverter module in enclosure size
F14.
5 = Rectifier module.
6 = Right rectifier module in enclosure size F14.
1 = Left most inverter module.
2 = Middle inverter module in enclosure sizes F12
or F13.
2 = Right inverter module in enclosure sizes F10
or F11.
