0-21 Display Line 1.2 Small
Option: Function:
Select a variable for display in line 1,
middle position.
[1662] Analog input The options are the same as those listed
*
53 for par. 0-20 Display Line 1.1 Small.
0-22 Display Line 1.3 Small
Option: Function:
Select a variable for display in line 1,
right position.
[1614] Motor The options are the same as those listed
*
Current for 0-20 Display Line 1.1 Small.
0-23 Display Line 2 Large
Option: Function:
Select a variable for display in line 2.
[1615] Frequency The options are the same as those listed for
*
par. 0-20 Display Line 1.1 Small
0-24 Display Line 3 Large
Option: Function:
[1652] Feedback [Unit] The options are the same as those
*
listed for 0-20 Display Line 1.1 Small.
Select a variable for display in line 2.
0-37 Display Text 1
Range: Function:
0 [0 - In this parameter, it is possible to write an individual
*
25 ] text string for display in the LCP or to be read via
serial communication. If to be displayed
permanently, select Display Text 1 in 0-20 Display
Line 1.1 Small, 0-21 Display Line 1.2 Small,
0-22 Display Line 1.3 Small, 0-23 Display Line 2 Large
or 0-24 Display Line 3 Large. Parameter 0-37 is linked
to Parameter 12-08 Host Name. Changing Parameter
12-08 will change Parameter 0-37 - but not in the
other direction.
0-38 Display Text 2
Range: Function:
0 [0 - In this parameter, it is possible to write an
*
25 ] individual text string for display in the LCP or to be
read via serial communication. If to be displayed
permanently, select Display Text 2 in 0-20 Display
Line 1.1 Small, 0-21 Display Line 1.2 Small,
0-22 Display Line 1.3 Small, 0-23 Display Line 2 Large
or 0-24 Display Line 3 Large. Press [
change a character. Press [
cursor. When a character is highlighted by the
cursor, this character can be changed. A character
can be inserted by placing the cursor between 2
characters and pressing [
MG20Y202
Operating Instructions
▲ ▼
] or [ ] to
◀ ▶
] and [ ] to move the
▲ ▼
] or [ ].
Danfoss A/S © Rev. 06/2014 All rights reserved.
0-39 Display Text 3
Range: Function:
0 [0 - In this parameter it is possible to write an
*
25 ] individual text string for display in the LCP or to be
read via serial communication. If to be displayed
permanently select Display Text 3 in 0-20 Display
Line 1.1 Small, 0-21 Display Line 1.2 Small,
0-22 Display Line 1.3 Small, 0-23 Display Line 2 Large
or 0-24 Display Line 3 Large. Press [
change a character. Press [
cursor. When a character is highlighted by the
cursor, this character can be changed. A character
can be inserted by placing the cursor between 2
characters and pressing [
0-70 Date and Time
Range: Function:
Size [ 0 - 0 ] Sets the date and time of the internal
related clock. The format to be used is set in
*
0-71 Date Format and parameter 0-72 Time
Format.
0-71 Date Format
Option: Function:
[0] YYYY-MM-DD Sets the date format to be used in the LCP.
[1] DD-MM-YYYY Sets the date format to be used in the LCP.
[2] MM/DD/YYYY Sets the date format to be used in the LCP.
0-72 Time Format
Option: Function:
Sets the time format to be used in the LCP.
[0] 24 h
[1] 12 h
0-74 DST/Summertime
Option: Function:
Select how daylight saving time/summertime
should be handled. For manual DST/summertime
enter the start date and end date in
parameter 0-76 DST/Summertime Start and
parameter 0-77 DST/Summertime End.
[0] Off
*
[2] Manual
0-76 DST/Summertime Start
Range: Function:
Size related [ 0 - 0 ] Sets the date and time when DST/
*
summertime starts. The date is
programmed in the format selected in
0-71 Date Format.
▲ ▼
] or [ ] to
◀ ▶
] and [ ] to move the
▲ ▼
] or [ ].
