3.2.4.2 Inverter, Enclosure Sizes F10 and F11

1
Illustration 3.12 Terminal Locations - Left, Front and Right Views. The gland plate is 42 mm below .0 level.
1) Ground bar
2) Motor terminals
3) Brake terminals
MG20Y202
Operating Instructions
2
6
Danfoss A/S © Rev. 06/2014 All rights reserved.
4
308.3 [12.1]
253.1 [10.0]
180.3 [7.1]
5
.0 [.0]
44.40 [1.75]
244.40 [9.62]
4
3
3 3
17
