How to programme the freque...
Parameter number and name
0-01 Language
Parameter 1-20 Motor Power [kW]
Parameter 1-22 Motor Voltage
Parameter 1-23 Motor Frequency
Parameter 1-24 Motor Current
Parameter 1-25 Motor Nominal Speed
Parameter 3-41 Ramp 1 Ramp Up Time
Parameter 3-42 Ramp 1 Ramp Down Time
Parameter 4-11 Motor Speed Low Limit [RPM]
Parameter 4-13 Motor Speed High Limit [RPM]
Parameter 1-29 Automatic Motor Adaptation (AMA)
Table 6.4 Q2 Quick Setup
6 6
6.1.4 Q3 Function Set-ups
The Function Set-up provides quick and easy access to all
parameters required for the majority of water and
wastewater applications including variable torque, constant
torque, pumps, dosing pumps, well pumps, booster
pumps, mixer pumps, aeration blowers and other pump
and fan applications. Amongst other features, it also
includes parameters for selecting which variables to display
on the LCP, digital preset speeds, scaling of analog
references, closed loop single zone and multi-zone
applications and specific functions related to water and
wastewater applications.
How to access Function Set-up - example:
1. Turn on the frequency converter (On LED lights)
Status
28.8%
Auto Remote Running
Illustration 6.2
2. Press the [Quick Menus] key (Quick Menus
choices appear).
Illustration 6.3
3.
Press [
Function Set-ups. Press [OK].
62
1 (1)
2.63kW
5.66A
14.4Hz
0kWh
13.7% 13.0A 1(1)
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
▲ ▼
]/[ ] navigation keys to scroll down to
Danfoss A/S © Rev. 06/2014 All rights reserved.
Operating Instructions
Unit
kW
V
Hz
A
Illustration 6.4
RPM
s
s
4.
RPM
RPM
Illustration 6.5
5.
Illustration 6.6
6.
Illustration 6.7
7.
Illustration 6.8
69.3% 5.20A 1(1)
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
Function Set-ups choices appear. Select Q3-1
General Settings. Press [OK].
1190 RPM 0.000 1 (1)
Function Setups Q3
Q3 - 1 General Settings
Q3 - 2 Open Loop Settings
Q3 - 3 Closed Loop Settings
▲ ▼
Press [ ]/[ ] keys to scroll down to i.e. Q3-12
Analog Outputs. Press [OK].
0.000 rpm 0.000 1 (1)
General Settings Q3-1
Q3 - 10 Clock Settings
Q3 - 11 Display Settings
Q3 - 12 Analog Output
Q3 - 13 Relays
Select parameter 6-50 Terminal 42 Output. Press
[OK].
0.000 rpm 0.000 1 (1)
Analog Output Q3-12
6 - 50 Terminal 42 Output
(100) Output frequency
▲ ▼
Press [ ]/[ ] keys to select between the different
choices. Press [OK].
0.000 rpm 0.000 1 (1)
Q3-12
Analog Output
6 - 50 Terminal 42 Output
(107) Speed
