22-85 Speed at Design Point [RPM]
Range: Function:
Size [ 0 - Resolution 1 RPM.
related 60000
*
Only visible when parameter 22-82 Work
RPM]
Point Calculation is set to [0] Disabled. Enter
the motor speed in RPM at which the
system design working point is achieved.
Alternatively, the speed in Hz can be
entered in parameter 22-86 Speed at Design
Point [Hz]. If it has been decided to use
RPM in 0-02 Motor Speed Unit then
parameter 22-83 Speed at No-Flow [RPM]
should also be used.
22-86 Speed at Design Point [Hz]
Range: Function:
Size [ 0.0 - Resolution 0.033 Hz.
related par.
*
Only visible when parameter 22-82 Work
4-19
Point Calculation is set to [0] Disabled. Enter
Hz]
the motor speed in Hz at which the system
design working point is achieved. Alterna-
tively, the speed in RPM can be entered in
parameter 22-85 Speed at Design Point [RPM].
If it has been decided to use Hz in
0-02 Motor Speed Unit, parameter 22-83 Speed
at No-Flow [RPM] should also be used.
22-87 Pressure at No-Flow Speed
Range: Function:
0 [ 0 - par. 22-88 ] Enter the pressure H
*
speed at no-flow in reference/feedback
units.
Also see parameter 22-82 Work Point Calculation point D.
22-88 Pressure at Rated Speed
Range:
999999.999 [ par. 22-87 -
*
999999.999 ]
22-83 Speed at No-Flow [RPM]
Range: Function:
Size [ 0 - Resolution 1 RPM.
related par. The speed of the motor at which flow is
*
22-85 zero and minimum pressure H
RPM] should be entered here in RPM. Alterna-
tively, the speed in Hz can be entered in
parameter 22-84 Speed at No-Flow [Hz]. If it
has been decided to use RPM in 0-02 Motor
Speed Unit then parameter 22-85 Speed at
Design Point [RPM] should also be used.
MG20Y202
Operating Instructions
corresponding to
MIN
Function:
Enter the value corresponding
to the pressure at rated speed,
in reference/feedback units. This
value can be defined using the
pump datasheet.
is achieved
MIN
Danfoss A/S © Rev. 06/2014 All rights reserved.
22-83 Speed at No-Flow [RPM]
Range: Function:
Closing the valves and reducing the speed
until minimum pressure H
determines this value.
Also see parameter 22-82 Work Point Calculation point C.
22-90 Flow at Rated Speed
Range: Function:
0 [0 - 999999.999 ] Enter the value corresponding to flow at
*
rated speed. This value can be defined
using the pump datasheet.
6.2.8 23-0* Timed Actions
Use Timed Actions for actions needing to be performed on
a daily or weekly basis, e.g. different references for working
hours/non-working hours. Up to 10 timed actions can be
programmed in the frequency converter. The timed action
number is selected from the list when entering parameter
group 23-0* Timed Actions from the LCP.
Parameter 23-00 ON Time – parameter 23-04 Occurrence
then refer to the selected timed action number. Each
timed action is divided into an ON time and an OFF time,
in which 2 different actions may be performed.
Display lines 2 and 3 in the LCP show the status for timed
actions mode (0-23 Display Line 2 Large and 0-24 Display
Line 3 Large, setting [1643] Timed Actions Status).
NOTICE
A change in mode via the digital inputs can only take
place if 23-08 Timed Actions Mode is set for [0] Times
Actions Auto.
If commands are applied simultaneously to the digital
inputs for Constant OFF and Constant ON, the timed
actions mode changes to timed actions auto and the 2
commands are disregarded.
If 0-70 Date and Time is not set or the frequency
converter is set to HAND or OFF mode (e.g. via the LCP),
the timed actions mode is changed to Timed Actions
Disabled.
The timed actions have a higher priority than the same
actions/commands activated by the digital inputs or the
Smart Logic Controller.
The actions programmed in timed actions are merged with
corresponding actions from digital inputs, control word via
bus and Smart Logic Controller, according to merge rules
set up in parameter group 8-5* Digital/Bus.
is achieved
MIN
