Introduction
The frequency converter complies with UL508C thermal
memory retention requirements. For more information,
refer to the section Motor Thermal Protection in the
product specific design guide.
NOTICE
Imposed limitations on the output frequency
(due to export control regulations):
From software version 6.72 onwards, the output
frequency of the frequency converter is limited to 590
Hz. Software versions 6x.xx also limit the maximum
output frequency to 590 Hz, but these versions cannot
be flashed, that is, neither downgraded nor upgraded.

1.5 Disposal

Do not dispose of equipment containing
electrical components together with
domestic waste.
Collect it separately in accordance with
local and currently valid legislation.

1.6 Abbreviations and Conventions

60° AVM 60° Asynchronous vector modulation
A Ampere/AMP
AC Alternating current
AD Air discharge
AEO Automatic energy optimisation
AI Analog input
AMA Automatic motor adaptation
AWG American wire gauge
°C
Degrees Celsius
CD Contant discharge
CM Common mode
CT Constant torque
DC Direct current
DI Digital input
DM Differential mode
D-TYPE Drive dependent
EMC Electro magnetic compatibility
ETR Electronic thermal relay
f Motor frequency when jog function is
JOG
activated.
f Motor frequency
M
f The maximum output frequency the frequency
MAX
converter applies on its output.
f The minimum motor frequency from
MIN
frequency converter
f Nominal motor frequency
M,N
FC Frequency converter
g Gramme
® ®
Hiperface Hiperface is a registered trademark by
Stegmann
MG20Y202
Operating Instructions
hp
HTL
Hz
I
INV
I
LIM
I
M,N
I
VLT,MAX
I
VLT,N
kHz
LCP
lsb
m
mA
MCM
MCT
mH
min
ms
msb
η
VLT
nF
NLCP
Nm
n
s
On-line/Off-line
Parameters
P
br,cont.
PCB
PCD
PELV
P
m
P
M,N
PM motor
Process PID
R
br,nom
RCD
Regen
R
min
RMS
RPM
R
rec
s
Danfoss A/S © Rev. 06/2014 All rights reserved.
Horsepower
HTL encoder (10-30 V) pulses - High-voltage
transistor logic
Hertz
Rated inverter output current
Current limit
Nominal motor current
The maximum output current
The rated output current supplied by the
frequency converter
Kilohertz
Local control panel
Least significant bit
Meter
Milliampere
Mille circular mil
Motion control tool
Millihenry inductance
Minute
Millisecond
Most significant bit
Efficiency of the frequency converter defined
as ratio between power output and power
input.
Nanofarad
Numerical local control panel
Newton meters
Synchronous motor speed
Changes to on-line parameters are activated
immediately after the data value is changed.
Rated power of the brake resistor (average
power during continuous braking).
Printed circuit board
Process data
Protective extra low voltage
Frequency converter nominal output power as
HO.
Nominal motor power
Permanent magnet motor
The PID regulator maintains the desired speed,
pressure, temperature, etc.
The nominal resistor value that ensures a
brake power on motor shaft of 150/160% for 1
minute
Residual current device
Regenerative terminals
Minimum permissible brake resistor value by
frequency converter
Root mean square
Revolutions per minute
Resistor value and resistance of the brake
resistor
Second
1 1
